Product Description
The M18 Force Logic 750 MCM crimper is the easiest way to crimp, producing cULus classified crimps according to the UL 486A-B classification standards for #8 - 750 MCM Cu and dual rated Anderson, Blackburn Burndy, Ilsco, Panduit, Penn-Union and Thomas & Betts connectors. Milwaukee EXACT 12T U-Style dies are individually engineered both for quality crimps and for faster connections on all sizes with die lengths specific to each connector. Additionally, every EXACT 12T u-style die features vivid industry standard colors to indicate wire size and center alignment markings for easiest die selection and die alignment. All dies also eliminate cross referencing by imprinting the wire size onto completed connectors and are the only dies that are 100% serialized and measured for greatest accuracy and easiest inspection.
Features:
- 350? Head Rotation Provides Easy Access in Tight Spaces
- Bold Alignment Marks aid accuracy in crimp placement
- Longer Life with POWERSTATE Brushless Motor & Weather Protected Electronics that Keep Dirt, Dust & Moisture Out
- Most Balanced with Ergonomic Grip Design
- PFM (Predictive Force Monitoring) Provides Instant Pressure Verification with Green Indicator
- Pre-Crimp Battery Check Automatically Ensures Enough Charge to Complete Each Crimp
- The Tool Records & Stores Every Crimp Made for Professional Report Building through ONE KEY
- The Tool Records & Stores Every Crimp Made for Professional Report Building through ONE KEY
Specifications:
- Output Force (t): 6
- Degree Head Rotation: 340
- Batteries Included: Yes
- Handle Grip Design: In line
- Batteries Included / Bare Tool: Battery Included
- Variable Speed: No
- Aluminum Lug Capacity: 8 AWG to 350 kcmil
- ONE-KEY Enabled: Yes
- Full Pressure Indicator: Yes
- Battery Series: M18
- Reporting and Tool Diagnostics: Built In - One Key Enabled
- Motor Type: Brushless
- Copper Lug Capacity: 8 AWG to 600 kcmil
- Adaptive Pressure Control System: Yes
- Battery Quantity Included: 0
- Balanced Center Grip: Yes
- Battery Voltage: 18
- Voltage Rating: 18V
- Auto Reset: Yes
- Crimp Speed (sec): 3
- Condition: New
- Maximum Operating Temperature (F): 140
- Crimper Head Style: Scissor
- Battery Composition: Lithium-Ion (Li-ion)
- Number of Batteries Required: 1
- Color Finish: Black; Red
- Battery Amp Hour (Ah): 2
- Battery Charger Input Voltage: 120
- Includes Charger: Yes
- Weight Excluding Battery (lb): 11.5
- Battery System: M18
- FUEL: No
- Material: Metal
- Brushless Motor: Yes
- Power Tool Branding: Brushless (Not FUEL)
- Badge Branding: Not Applicable
- ONE-KEY Baseline (Track, Manage, Lock): Yes
- ONE-KEY Adaptive Features: Lock; Manage; Quality Assurance Reporting; Track
- Number of Batteries Included: 2
- Corded Cordless: Cordless
- Powered Tool Power Source: Electric - Cordless
Includes:
- (1) M18 FORCE LOGIC 750 MCM Crimper (2779-22)
- (1) M18 REDLITHIUM CP2.0 Battery (48-11-1820)
- (1) M18 REDLITHIUM XC5.0 Extended Capacity Battery Pack (48-11-1850)
- (1) M18 & M12 Multi-Voltage Charger (48-59-1812)
- (1) Carrying Case
