The new Laguna Fusion Table Saws are unlike any saw on the market. Having the same quality demands earned through the original fusion table saw, the new fusion line will not only impress but exceed the expectations you have come to expect from Laguna. With a completely redesigned trunnion and arbor controls that focuses on buttery smooth controls and longevity of the saw, we are sure this is the saw that will give you the perfect rip cut for many many years.
Features:
- 3HP TEFC Motor
- 220V, Single-Phase, 60Hz Power Requirement
- Fusion Dust Collection System
- Industrial Cabinet, Fence & Trunnions
- Included Tools, Tables & Integrated Tool Storage
- Included 10" x 60T Carbide-Tipped Blade
- Industrial 14 Gauge Cabinet
- Accessory Tables (Outfeed & Rip)
- Industrial Fence Rail
- Industrial Fusion Fence
- Premium Electrical & Hardware Components
- Premium Miter Gauge
- Cast Iron Fusion Trunnions
- Cabinet Mounted Arbor
- Cast Iron Table & Wings
- European Hi-Lo Fence
- Premium Zero Clearance Throat Plate
- Fusion Hi-Lo Dust Collection
- Magnetic Contractor Switch
- Quick-Release Blade Guard and Spreader
- Riving Knife Included
- Push Stick Included
- Miter Gauge Included
- Blade Changing Tool Included
- Integrated Tool Storage
- 10 x 60T Carbide-Tipped Blade Included
- Premium Arbor & Motor Bearing
Additional Specs:
- Dust Port Size: 4 in.
- Blade Guard Dust Port Size: 1½ in.
- Table Saw Type: Cabinet
- Maximum Blade Diameter: 10 in.
- Arbor Size: ⅝ in.
- Arbor Speed: 4500 RPM
- Maximum Width Of Dado: ¾ in.
- Blade Tilt Direction: Left
- Max Blade Tilt: 45°
- Maximum Depth Of Cut At 90°: 3 …› in.
- Maximum Depth Of Cut At 45°: 2 …› in.
- Max Rip Right Of Blade With Included Fence & Rails: 37 in.
- Max Rip Left Of Blade With Included Fence & Rails: 19 11/16
Blade Information
- Included Blade Information: 10€³ x 60T
- Riving Knife/Spreader Thickness: 3/32€³
- Required Blade Body Thickness: > …›€
- Required Blade Kerf Thickness: < 5/64€³
Table Information
- Floor To Table Height: 35€³
- Table Size With Extension Wing Width: 61€³
- Table Size With Extension Wings Depth: 27€³
- Distance €“ Front Of Table To Center Of Blade: 13 7/16€³
- Distance €“ Front Of Table To Blade At Maximum Cut: 8 …€
- Main Table Size Thickness: 1 ½€
Fence Information
- Fence Type: Camlock T-Shape With Aluminum European Hi-Lo Face
- Fence Size Length: 33 7/16€³
- Fence Size Width: 16€³
- Fence Size Height: 3€³
- Fence Rail Type: Aluminum Extrusion/Angle Steel
- Fence Rail Length: 67 ⅞€
- Fence Rail Width: 3€³
- Fence Rail Height: 2€³
Product Dimensions
- Weight (Net): 385 lbs
- Overall Width (Side-To-Side): 69€³
- Overall Depth (Front-To-Back): 56€³
- Overall Height: 43€³
- Footprint Width: 20 ½€
- Footprint Length: 42 ½€
- Space Required For Full Range Of Movement Width (Side-To-Side): 69€³
- Space Required For Full Range Of Movement Depth (Front-To-Back): 56€³
Construction Information
- Table: Precision-Ground Cast Iron
- Wings: Precision-Ground Cast Iron
- Cabinet: 14 Gauge Steel
- Trunnions: Cast Iron
- Body Assembly: 14 Gauge Steel
- Fence Assembly: Steel Body
- Rails: Industrial Steel
- Miter Gauge Construction: Cast Iron With Steel Bar
- Guard: Steel And Clear Plastic
- Body/Cabinet Paint Type/Finish: Powder Coated
- Arbor Bearings: Sealed & Permanently Lubricated
