Laguna MDCBF1110C1M - B|Flux

$799.00
SKU:
LAGMDCBF1110C1M
Weight:
71.00 LBS
Availability:
Usually in Stock and Ships in a Few Business Days
Shipping:
$100.00 (Fixed shipping cost)
Qty:

Product Details

The best looking single stage dust collector to hit the market in years. Sleek design and power to match. No more fumbling with a steel band to mount your lower bag, the b|flux comes with a patented Snap-Band that makes changing the bag a breeze. Unlike most 1HP units the b|flux feels solid & has a low dB rating. The horizontal dust chute provides optimum airflow & can swivel 180° to make the 4″ outlet face downwards.

The B|Flux:1 comes standard with a 1 micron canister providing filtration of 99.97% of particles between 0.2 ~ 2 microns & features 17.2 square feet of polyester spun bond pleated filter to ensure maximum airflow. Hand crank cleaning prevents clogging of the filter.

Features:

  • Motor: 1HP
  • Phase: 1
  • Voltage: 110v
  • Amps: 8.4 Amps
  • Recommended Breaker: 15 Amps
  • Hertz: 60

Additional Details:

  • Plug: Yes
  • RPM: 3450
  • Switch Type: Motor Mounted Direct Switch
  • Hand Held Remote: None
  • Shop Setting CFM: 550
  • Inlet CFM: 650
  • Max Static Pressure (Inches of Water): 4.86″
  • Impeller/Fan Size: 9″
  • Impeller Material: Steel
  • Impeller Type: Radial Fin
  • Balanced To: ISO 1940
  • Inlet Diameters: 4″ x 1 Port
  • Drum Collection Bag (Dia. x L): Plastic Bag (350 x 980mm)
  • Canister Filter Type: 1 Micron
  • Filtration Efficiency: 0.2 – 2 Micron at 99.97%
  • MERV Rating: 12
  • Canister Diameter: 360mm (14.2″)
  • Canister Length: 300mm (11.8″)
  • Filter Surface Area: 1.6m² / 17.2ft²
  • Canister Cleaning: Manual Handle Crank 360°
  • Wheels: 2″ Ball Caster
  • CSA Approved: Yes
  • Decibel Reading: 76 dB (At 9.8ft)
  • Assembled Dimensions (L x W x H): 29″ x 14.8″ x 50.4″ | 736 x 376 x 1280mm
  • Shipping Weight: 77lbs
  • Shipping Dimensions (L x W x H): 32″ x 20″ x 25″
