Laguna MDCBF1110C1M - B|Flux

The best looking single stage dust collector to hit the market in years. Sleek design and power to match. No more fumbling with a steel band to mount your lower bag, the b|flux comes with a patented Snap-Band that makes changing the bag a breeze. Unlike most 1HP units the b|flux feels solid & has a low dB rating. The horizontal dust chute provides optimum airflow & can swivel 180° to make the 4″ outlet face downwards.

The B|Flux:1 comes standard with a 1 micron canister providing filtration of 99.97% of particles between 0.2 ~ 2 microns & features 17.2 square feet of polyester spun bond pleated filter to ensure maximum airflow. Hand crank cleaning prevents clogging of the filter.

Features:

• Motor: 1HP
• Phase: 1
• Voltage: 110v
• Amps: 8.4 Amps
• Recommended Breaker: 15 Amps
• Hertz: 60

Additional Details:

• Plug: Yes
• RPM: 3450
• Switch Type: Motor Mounted Direct Switch
• Hand Held Remote: None
• Shop Setting CFM: 550
• Inlet CFM: 650
• Max Static Pressure (Inches of Water): 4.86″
• Impeller/Fan Size: 9″
• Impeller Material: Steel
• Impeller Type: Radial Fin
• Balanced To: ISO 1940
• Inlet Diameters: 4″ x 1 Port
• Drum Collection Bag (Dia. x L): Plastic Bag (350 x 980mm)
• Canister Filter Type: 1 Micron
• Filtration Efficiency: 0.2 – 2 Micron at 99.97%
• MERV Rating: 12
• Canister Diameter: 360mm (14.2″)
• Canister Length: 300mm (11.8″)
• Filter Surface Area: 1.6m² / 17.2ft²
• Canister Cleaning: Manual Handle Crank 360°
• Wheels: 2″ Ball Caster
• CSA Approved: Yes
• Decibel Reading: 76 dB (At 9.8ft)
• Assembled Dimensions (L x W x H): 29″ x 14.8″ x 50.4″ | 736 x 376 x 1280mm
• Shipping Weight: 77lbs
• Shipping Dimensions (L x W x H): 32″ x 20″ x 25″
