Description:
- Safety guard with limit switch protection
- Magnetic line interruption switch needs a restart after a power failure
- Head swivels 180° and is easily raised and lowered
- Head travels up to 14"
- Spindle is equipped with heavy-duty tapered bearings
- Powerful 1.5 HP single phase motor
- Magnetic line interruption switch and safety guard with limit switch protection
- Complete with forward reverse switch, 1/2" chuck with key, safety guard and stand
Specifications:
- MODEL - KC-35
- DRILLING CAPACITY - 1-1/4"
- MAX. DISTANCE SPINDLE NOSE TO TABLE - 21-1/4"
- SWING - 38-1/2"
- SPINDLE - MT #3
- SPINDLE STROKE - 5-1/4"
- COLUMN DIAMETER - 4-1/2"
- SPEEDS (RPM) - 5 (340-3,000)
- TABLE DIMENSIONS - 21-5/8" x 19-5/8"
- HEAD TRAVEL - 14"
- SIZE OF T-SLOT ON TABLE - 5/8"
- MOTOR - 8.8 Amp
- VOLTAGE - 220V, 1 phase, 60 Hz
- DIMENSIONS (LXWXH) - 34" x 24" x 90"
- SHIPPING WEIGHT - 638 lbs
- UPC - 7 72995 35000 1
