Innovation For The Trades„¢. The DEWALT U-Type Died Crimping Tool (DCE300) delivers a 12-ton crimping force for UL classified crimps using compatible connectors from leading manufacturers. It accepts U Type dies from all brands and has a capacity from #8 €“ 750 MCM Cu /Al. A 270° pivoting head allows the crimper to maneuver in tight spaces while forward and reverse trigger switches offer convenient one-handed operation. The tool features Crimp Connect„¢ software, an onboard intelligence system integrated into the tool that provides detailed reports of date, time, force, and successfully completed cycles of the crimps completed by the tool. Crimp Connect„¢ software also reports on tool calibration and service history. An integrated LED interface is used to communicate power on or power off, battery state of charge, cycle completion, and if recalibration or service is needed. A bright LED light helps to illuminate the crimping area when working in dark spaces. The tool also includes attachment points and a shoulder strap for convenience when transporting around the jobsite.
- 270° pivoting head allows the crimper to maneuver in tight spaces
- 750 McM Cu / 750 Al crimping capacity for copper and aluminum cable
- Accepts all U-Type Dies and completes UL Certified Crimps with leading manufacturers connectors & dies (See user manual for compliant chart of dies and connectors)
- Bright LED light help to illuminate work area
- Cable Capacity: 750 MCM Cu / Al
- Crimp Connect„¢ software provides detailed reports of work done
- Die Type: 8796750000000
- Easily accessible forward and reverse for one-handed operation
- Force: 12 Tons
- Handle Configuration: 8796750000000
- Material: 8796220000000
- Material: 8796750000000
- Onboard diagnostics indicates battery life successfully completed cycles, service needed, and operating temperature range
- Power Tool Type: 8796390000000
- Shoulder strap and connection ring for portability
- System: 8796390000000
- Tool Height: 14
- Tool Length: 17.5
- Tool Weight: 14.6
- Application:Crimping # 8 - 750 MCM Cu / 750 Aluminum
- categoryName:Cutting and Crimping [8153]
- Includes:DCE300, (2) DCB204 4 Ah Li-Ion batteries, DCE115 Charger, Shoulder Strap, Kitbox
- Item Weight:29
- Length:23.43
- originCountry:FR
- Volume:1.143
- Warranty:90 Day Money Back Guarantee
- Warranty 2:1 Year Limited Warranty
- Warranty 3:3 Year Limited Warranty"
