Product Description
Heavy duty True-RMS meter for professional residential, commercial and industrial applications. The perfect tool for the professional commercial or industrial electrician; includes the features that are needed to get the job done in the field, on-site or in the plant. Milwaukee 2216-20 digital multimeter features: true RMS measurement to accurately measure all applications; CATIII 600 V for increased safety in demanding electrical environments; AC voltage range of 6 millivolts to 600 V; DC voltage range of 600 millivolts to 600 V DC; resistance measurement from 600 ohms to 40 m Ohm; frequency measurement from 10 Hz to 50 kilohertz; detects continuity at less than 30 ohms; current measurement to 10 A AC/DC; hold function, min/max function and digital bar graph readout; black on white display and backlight for easier reading; rugged over-molding for improved durability and user grip; proprietary rail system for mounting accessories.
Features:
- True-RMS for accurate measurement in all applications
- Wide Voltage range to 600 AC /DC volts
- Auto Range to mV
- Frequency measurements from 10Hz to 50kHz
- Current Measurement to 10A AC/DC
- Rugged over-molding increases durability and user grip
- CAT III 600V for increased safety
- Capacitance to 1000 ?F
Specifications:
- Digital/Analog: Digital
- Auto Ranging: Yes
- AC Response: TRMS
- Temperature Range: -40 Degrees to 752 Degrees F
- Display Design: Backlit Black On White LCD
- Instrument Counts: 9999
- DC Amperage Maximum: 10
- Audible Continuity: Yes
- Operating Temperature Range: not available
- DC Basic Accuracy Range: +/-0.05% of Reading + 2 Digits
- Peak Hold: Yes
- Case Included: No
- Capacitance Range & Resolution: 0.1-1000
- Capacitance Range: 10 pF to 1000 uF
- DC Current Range & Resolution: 0.001-10.00A
- Continuity Beeper: Yes
- Frequency Range: 50 kHz
- Resistance Capable: Yes
- Multiple On-Screen Displays: No
- Resistance Range & Resolution: 600 Ohm to 40 mOhm
- PC Log: No
- DC Capable: Yes
- Max. Ohms: 40000000
- Frequency Capable: Yes
- Min/Max/Avg Feature: Yes
- AC Voltage Maximum: 600
- DC Voltage Maximum: 600
- Additional Contents: Electrical Test Lead Set, (2) AA Batteries, NIST Certificate of Calibration with Data, Manual
- Test Lead Probe Ends: Electrical
- AC Amperage Maximum: 10
- Data Hold: Yes
- AC Capable: Yes
- Instrument Frequency Counter Range: 10 Hz to 50 kHz
- Capacitance Capable: Yes
- Battery Size: AA
- AC Current Range & Resolution: 0.001-10.00A
- Detachable Display Screen: No
- Current Clamp: No
- Duty Cycle Capable: No
- Display Type: Digital
- Temperature Capable: No
- Bar Graph: Yes
- Color Finish: Black; Red
- Case Color: Black; Red
- AC Voltage Range: 6mV to 600V
- Weight (lb): 20.8
- Material: Plastic
- DC Volts: 6.00mV - 600V
Includes:
- (1) Digital Multimeter (NIST) (2216-20NST)
- (2) AA Batteries
- (1) Manual
- (1) Test Lead Set
- (1) NIST Certificate of Calibration with Data
