Product Description
Features & Benefits:
- Thumb Switch With Lock-On (AC)
- "SJS II" Technology, Variable Speed, Mechanical Brake, Electronic Current Limiter, Constant Speed Control, Soft Start
- SJS II (Super Joint System II) reduces vibration and prevents kickback during wheel lock up for optimal tool and operator protection
- Mechanical brake for increased operator safety
- Electronic current limiter prevents motor burnout due to overloading
- Soft start feature gradually increases speed to eliminate start up shock
- Constant speed control maintains constant speed under heavy load
- Re-Designed gear housing for enhanced shaft lock durability
- Labyrinth construction features a complex series of channels to prevent penetration of dust and debris into the field and armature for maximum operational life
- Motor winding protection features "zig-zag" varnish on the armature and hardened powder on the field coils to act as an impenetrable barrier to dust and debris
- Rotatable gear housing can be positioned at every 90o for optimal positioning
- Removable side handle can be mounted on left or right side of tool
- Slim housing design for easy handling and maneuverability
Specifications:
- Maximum Capacities:
- Grinding Wheel --4-1/2" (115 mm)
- Sanding Disc --4-1/2" (115 mm)
- Diamond Wheel --4-1/2" (115 mm)
- Wire Cup Brush --3-1/2" (90 mm)
- Spindle Thread: -- 5/8" - 11 UNC
- No Load Speed: --2,800 - 11,000 RPM
- AMPS (120 V) --12.0 A
- Vibration Level --6.0 m/s2
- Noise Level --86 dB(A)
- Overall length --12-3/4" (325 mm)
- Net Weight --5.9 lbs (2.7 kg)
Standard Equipment:
4-1/2" Depressed Center Wheel (1 Ea. A-80640), Anti-Vibration Side Handle(194514-0), Lock Nut Wrench 28 (782412-6), Toolless Wheel Cover (123144-0), Inner Flange (224448-4), Lock Nut 5/8-45(224568-4)
