Product Description
Description:
- Powerful 2 HP motor
- Swivel base from 0° to 45°
- Position adjustable control panel and automatic shut-off
- Adjustable hydraulic down feed control
- Carbide ball bearing blade guides
- To ensure reliable accurate cuts, both adjustable control arms can be positioned as close to the cut as possible
- Exclusive 24 Volt control panel
- Coolant system with regulator valves provide an even flow of coolant to the blade
- TRU-LOCK™ quick locking vise system
Specifications:
- CUTTING CAPACITY AT 90°: Rect. 10" x 18" ? Diam. 10"
- CUTTING CAPACITY AT 45°: Rect. 7-7/8" x 7-7/8" ? Diam. 7-7/8"
- VARIABLE SPEEDS: 73-312 FPM
- BLADE: 121-3/4" x 1" x 0.035"
- TABLE HEIGHT FROM FLOOR: 30"
- MOTOR: 2.6 Amp.
- VOLTAGE: 600V, 3 phase, 60 Hz
- ASSEMBLED DIMENSIONS (LXWXH) / WEIGHT: 81" x 28" x 48" / 845 lbs
- PACKAGING DIMENSIONS (LXWXH) / WEIGHT: 73" x 32" x 51" / 980 lbs
