Description:
- Slitting Shear up to 16 gauge
- BSS 1.6 CE
- Easy-to-use and curve-compatible slitting shear with integrated chip cutter.
Benefits:
- Chip cutter for clipping off the cut chip at any point.
- Left and right curve cuts and distortion-free cutting possible with one continuous chip.
- Rapid performance due to excellent view of the cutting line through the open-front cutting head.
- Excellent ergonomics and low weight.
- Motor with outstanding performance and durability.
- Cutting blade with outstanding service life.
- 16 ft. [5 m] cable.
- Clean swarf removal prevents injuries or scratches on workpieces.
- Stainless steel up to 18 gauge [1.2 mm].
- Wide range of accessories.
- ¹ with blade for curves.
Technical Data:
- Power consumption: 350 W
- Power output: 210 W
- Strokes: 2,100 - 4,500 spm
- Cutting speed: 19.7 [6] - 32.8 [10] ft/min[m/min]
- Steel 58,000 lbf/in²: 0.063 [1.6] in[mm]
- Steel 87,000 lbf/in²: 0.0472 [1.2] in[mm]
- Steel 116,000 lbf/in²: 0.0394 [1.0] in[mm]
- Non-ferrous metals up to 36,000 lbf/in²: 0.0787 [2.0] in[mm]
- Cutting width: 1/4 [5] in[mm]
- Radius of smallest curve: 3-1/2 [90] (1-1/4 [30] )¹ in[mm]
- Immersion dia.: 1/2 [15] (1/4 [8] )¹ in[mm]
- Cable with plug: 16.4 [5] ft[m]
- Weight: 3.31 [1.50] lbs[kg]
Includes:
- 1 blade, straight, up to 16 gauge [1.6 mm]
- 1 pair of cutting bars
- 1 wrench
