Product Description
Description:
- 4-speed cordless drill/driver
- ASCM 18 QM
- 4-Speed cordless drill/driver with brushless motor and QuickIN MAX interface. Uncompromising power for drilling and tapping up to 1/2 [12] in[mm] and drilling with carbide hole saws.
Benefits:
- Fully encapsulated and dustproof brushless FEIN PowerDrive motor with 30% greater efficiency and longer service life.
- 4-speed solid metal gearbox. Optimum speeds for drilling in metal and driving self-drilling screws.
- QuickIN MAX accessory interface for all QuickIN and QuickIN MAX accessories. Fast change between applications.
- High torques up to 797 [90] in/lbs[Nm].
- Includes QuickIN solid metal drill chuck (1,062 [120] in/lbs[Nm]) with carbide jaws and high clamping force.
- Optimal speed (3,850 rpm) in 4th gear for small diameters.
- Optimal speed (1,950 rpm) in 3rd gear for 3/8 [8] in[mm] dia.
- Cut threads efficiently in 1st gear.
- Electronic torque setting.
- Drives 3/8 x 15-3/4 in [10 x 400 mm] screws without pre-drilling.
- 2,500 screw applications (3/16 x 1-9/16 [5 x 40] in[mm] in wood) with one battery charge (6 Ah).
- One charger for all voltage classes of FEIN Li-ion batteries.
- The battery capacity can be read directly on the battery.
- FEIN SafetyCell technology. Protects the battery and the machine from overloading, overheating and deep discharge.
Technical Data:
- Battery voltage: 18 V
- Battery capacity: 6 Ah
- Battery compatibility: Li-ion / HighPower Li-ions
- Battery interface: 18 V
- Motor: brushless
- Gearbox: 4-speed
- Accessory interface: QuickIN MAX
- No load speed: 400 / 800 / 1,950 / 3,850 rpm
- Max. torque (hard/soft): 797 [90] / 398 [45] in/lbs[Nm]
- Torque steps: 15 + 1
- Chuck capacity: 1/16 [1.5] - 1/2 [13] in[mm]
- Fastening: 3/8 [10] x 15-3/4 [400] in[mm]
- Capacity in steel Ø: 31/32 [25] in[mm]
- Capacity in wood Ø: 1-31/32 [50] in[mm]
- Tapping: M 12
- Weight incl. battery: 4.85 [2.20] lbs[kg]
- Weight without battery: 3.31 [1.50] lbs[kg]
Includes:
- 2 rechargeable batteries (Li-ion)
- 1 rapid charger ALG 80
- 1 QuickIN drill chuck (1,062 [120] in/lbs[Nm])
- 1 belt clip
- 1 bit garage
- 1 handle
- 1 tool case
