Product Description
Description:
- 4-speed cordless drill/driver
- ASCM 12 QC
- 4-speed cordless drill/driver with brushless motor and QuickIN interface. Ideal for drilling and tapping up to 3/8 [8] in[mm].
Benefits:
- Brushless FEIN PowerDrive motor with 30% greater efficiency and longer service life.
- 4-speed solid metal gearbox. Optimum speeds for drilling in metal and driving self-drilling screws.
- QuickIN accessory interface for all QuickIN accessories. Fast change between applications.
- High torques up to 354 [40] in/lbs[Nm].
- Includes small QuickIN all-metal chuck (531 [60] in/lbs[Nm]) with high concentricity accuracy.
- Optimal speed (2,500 rpm) in 4th gear for up to 1/4 [6] in[mm] dia.
- Mechanical torque setting.
- Stands safely on battery.
- Slim handle dimensions.
- 450 screw applications (3/16 x 1-9/16 [5 x 40] in[mm] in wood) with one battery charge (3 Ah).
- One charger for all voltage classes of FEIN Li-ion batteries.
- The battery capacity can be read directly on the battery.
- FEIN SafetyCell technology. Protects the battery and the machine from overloading, overheating and deep discharge.
Technical Data:
- Battery voltage: 12 V
- Battery capacity: 3 Ah
- Battery compatibility: Li-ion
- Battery interface: 12 V
- Motor: brushless
- Gearbox: 4-speed
- Accessory interface: QuickIN
- No load speed: 400 / 700 / 1,400 / 2,500 rpm
- Max. torque (hard/soft): 354 [40] / 177 [20] in/lbs[Nm]
- Torque steps: 20 + 1
- Chuck capacity: 1/16 [1.5] - 1/2 [13] in[mm]
- Fastening: 3/8 [8] x 7-7/8 [200] in[mm]
- Capacity in steel Ø: 1/2 [13] in[mm]
- Capacity in wood Ø: 1-9/16 [40] in[mm]
- Tapping: M 8
- Weight incl. battery: 3.09 [1.40] lbs[kg]
- Weight without battery: 2.43 [1.10] lbs[kg]
Includes:
- 2 rechargeable batteries (Li-ion)
- 1 rapid charger ALG 50
- 1 QuickIN drill chuck (531 [60] in/lbs[Nm])
- 1 belt clip
- 1 bit garage
- 1 tool case
