Product Description
- 15.0 Amp motor uses state-of-the-art circuitry for soft starts and smooth operation
- Full wave electronic variable speed motor runs at 8,000-22,000 rpm with constant speed under load to ensure a quality finish in all materials
- Rack and pinion depth adjuster, magnified scale and micro-fine bit depth adjuster provides fast and accurate depth settings
- Phosphorous bronze bushings provide a smooth and accurate plunge
- Spindle lock button allows for single-wrench bit changes
- Dust Extraction Adapter for cleaner work sites
- 1/4" - 1/2" collet capacity for greater versatility
- Guide Bushing adapter plate accepts standard guide bushings for template work
- One-piece motor shaft and spindle ensures perpendicularity and accuracy
Specifications
| Amps | 15.0Amps |
|---|---|
| Horsepower | 3HP |
| No Load Speed | 8,000-22,000rpm |
| Collet Diameter | 1/2", 1/4" |
| Plunge Stroke | 2-7/16" |
| Depth Stop | 3 Stage Turret Stop |
| Base Dimension | 5-5/8 x 6-11/16" |
| Spindle Lock | Yes |
| Tool Weight | 11.2lbs |
| Shipping Weight | 16.0lbs |
Includes:
- 1/4" collet
- 1/2" collet
- Dust Extraction Adapter
- Template guide bushing adapter
- Wrench
