Product Description
- Ideal for use in woodworking, building construction and agriculture industries.
- The DMM-001 is also an invaluable tool in the restoration field.
- Ideal for locating moisture in carpets and sub-flooring.
- Ultra-sensitive Digital Moisture Meter easily detects hidden leaks in wood, concrete, plaster and carpet.
- Providing accurate moisture level readings make this tool great for new home inspections, locating roof leaks or even selecting dry lumber at the yard.
- Display will show the moisture content in Percent Moisture Content directly.
Technical Details:
- Moisture measuring range: 5~50% (in wood); 1.5~33% (in building material)
- Measuring accuracy: ±2%
- Backlight shut off: Approx. 15 seconds
- Auto power off: After 3 minutes idle
- Battery: Included
- Battery Type: 9V Battery Block (6F22 or 6LR6); Alkaline
- Low battery indicator: <7V
- Working current: <25mA
- Working temperature: 32°F~122°F
- Working humidity: <90%RH non-condensing
- Storage: -4°F~140°F ≤85% (without battery)
- Dimensions: 145 x 65 x 25mm (5-11/16” x 2-9/16” x 1”)
- Weight: About 3oz (without battery)
Measures moisture content by detecting a material’s electrical resistivity using two pins.
Measurement output is displayed on a practical LCD screen.
Instruction manual.
Details:
1) Pull out protection cover, remove protection caps from the pins.
2) Press power button to switch on tool. LOW LED will turn on, and LCD will display “_ _ _”. Default measuring mode is for wood. Press button MODE to switch material.
3) Insert the two detection pins into the target material.
4) Wood mode shows a moisture percentage between 5% and 50%. Below 5% screen will display "_ _ _", whereas over 50% screen will display "- - -".
5) Building material mode shows a moisture percentage between 1,5% and 33%. Below 1,5% screen will display "_ _ _", whereas over 33% screen will display "- - -".
6) Press HOLD button when measuring to store data. Press button again to deactivate function.
7) Keep pressing HOLD button to turn off the buzzer sound when measuring.
8) Keep pressing power button for 2 seconds to switch off tool.
2) Press power button to switch on tool. LOW LED will turn on, and LCD will display “_ _ _”. Default measuring mode is for wood. Press button MODE to switch material.
3) Insert the two detection pins into the target material.
4) Wood mode shows a moisture percentage between 5% and 50%. Below 5% screen will display "_ _ _", whereas over 50% screen will display "- - -".
5) Building material mode shows a moisture percentage between 1,5% and 33%. Below 1,5% screen will display "_ _ _", whereas over 33% screen will display "- - -".
6) Press HOLD button when measuring to store data. Press button again to deactivate function.
7) Keep pressing HOLD button to turn off the buzzer sound when measuring.
8) Keep pressing power button for 2 seconds to switch off tool.
